Description
The ultrasonic atomizing nozzle breaks the interaction between liquid molecules through the high-frequency vibration generated by the ultrasonic vibrator, thereby dispersing the liquid into countless tiny droplets. These droplets form aerosols in the air to achieve the effect of atomization.
Main features
1. Efficient atomization: Ultrasonic atomizing nozzles can quickly atomize liquid into tiny particles, with uniform and fine droplets and high atomization efficiency.
2. Energy saving and environmental protection: The nozzle uses ultrasonic technology and does not require heating or high-pressure gas, so it has low energy consumption and does not produce harmful substances during use, which meets environmental protection requirements.
3. Easy to adjust: Ultrasonic atomizing nozzles usually have adjustable atomization volume, spray angle and spray distance, which can be flexibly adjusted according to actual needs.
4. Wide application: The nozzle can be used in humidification, cooling, dust removal, disinfection and other occasions, such as industrial humidification, agricultural irrigation, mine dust removal, medical disinfection, etc.
Tech. info:
| Atomized particles | 15-40um |
| Spraying width | 40-80mm |
| Spray flow | 0.5-20ML/min |
| Spray height | 30-80mm |
| Suitable for liquid viscosity | <30cps |
| Suspension particle size | <15um |
| Diversion air pressure | <0.05mpa |
Applications
Electronics: Photoresists onto Wafer ,Sensors, PCB Fluxing, Semiconductors etc.
Industrial: Glass, Touch Screen, etc.
Medical: Medical Textile,Stents, Balloon Catheters, Diagnostic Device etc.
Energy: Fuel Cell, Solar Cell, etc.
