| Availability: | |
|---|---|
| Quantity: | |
| Place of Origin | China |
|---|---|
| Brand Name | RPS-SONIC |
| Certification | CE |
| Model Number | RPS-SONO20-1000 |
| Minimum Order Quantity | 1pcs |
| Price | Negotiable |
| Packaging Details | CARTON/WOODEN |
| Delivery Time | 1DAYS |
| Payment Terms | T/T |
| Supply Ability | 200PCS/MONTH |
Parameter
| Model | SONOL20-1000 | SONOL20-500 | SONOL28-300 | SONOL40-100 |
| Frequency | 20±0.5 KHz | 20±0.5 KHz | 28±0.5 KHz | 40±0.5 KHz |
| Power | 1000 W | 500 W | 300 W | 100 W |
| Voltage | 220/110V | 220/110V | 220/110V | 220/110V |
| Temperature | 300 ℃ | 300 ℃ | 300 ℃ | 300 ℃ |
| Pressure | 35 MPa | 35 MPa | 35 MPa | 35 MPa |
| Max Capacity | 8 L/Min | 5 L/Min | 1L/Min | 0.5 L/Min |
| Tip Head Material | Titanium Alloy | Titanium Alloy | Titanium Alloy | Titanium Alloy |
Description
The working principle of ultrasonic emulsification mixing equipment is mainly based on the cavitation effect of ultrasound. Under the action of strong ultrasound, a large number of bubbles will be generated in the liquid. These bubbles will gradually grow and increase with the ultrasonic vibration, and then suddenly burst and split. The rapid collapse of the bubbles generates high temperature and high pressure in the bubbles, and because the liquid around the bubbles rushes into the bubbles at high speed, a strong micro-jet is generated in the liquid near the bubbles, forming a local high temperature and high pressure environment, thereby producing a crushing and emulsification effect. This effect causes one liquid to be dispersed into smaller particles and evenly distributed in another liquid to form a stable emulsion or mixed liquid.
Equipment features
1. Efficient emulsification: Ultrasonic emulsification mixing equipment can achieve efficient emulsification, mixing and dispersion in a short time, improving production efficiency.
2. Energy saving and environmental protection: The equipment adopts ultrasonic technology, does not need to add chemical reagents, is pollution-free and noise-free, and meets environmental protection requirements.
3. Easy to operate: The equipment is simple to operate and easy to control, and the frequency and power of the ultrasonic wave can be adjusted as needed.
4. Strong adaptability: It is suitable for the emulsification, mixing and dispersion of a variety of liquid materials, such as oil, water, pigments, glue, etc.
Ultrasonic emulsification mixing equipment is widely used in food, chemical, pharmaceutical, cosmetic and other industries. In the food industry, it can be used to make emulsified oil, jam, juice, etc.; in the chemical industry, it can be used to prepare pigments, coatings, glue, etc.; in the pharmaceutical industry, it can be used to prepare drug emulsions, vaccines, etc.; in the cosmetics industry, it can be used to make lotions, creams, etc.
Parameter
| Model | SONOL20-1000 | SONOL20-500 | SONOL28-300 | SONOL40-100 |
| Frequency | 20±0.5 KHz | 20±0.5 KHz | 28±0.5 KHz | 40±0.5 KHz |
| Power | 1000 W | 500 W | 300 W | 100 W |
| Voltage | 220/110V | 220/110V | 220/110V | 220/110V |
| Temperature | 300 ℃ | 300 ℃ | 300 ℃ | 300 ℃ |
| Pressure | 35 MPa | 35 MPa | 35 MPa | 35 MPa |
| Max Capacity | 8 L/Min | 5 L/Min | 1L/Min | 0.5 L/Min |
| Tip Head Material | Titanium Alloy | Titanium Alloy | Titanium Alloy | Titanium Alloy |
Description
The working principle of ultrasonic emulsification mixing equipment is mainly based on the cavitation effect of ultrasound. Under the action of strong ultrasound, a large number of bubbles will be generated in the liquid. These bubbles will gradually grow and increase with the ultrasonic vibration, and then suddenly burst and split. The rapid collapse of the bubbles generates high temperature and high pressure in the bubbles, and because the liquid around the bubbles rushes into the bubbles at high speed, a strong micro-jet is generated in the liquid near the bubbles, forming a local high temperature and high pressure environment, thereby producing a crushing and emulsification effect. This effect causes one liquid to be dispersed into smaller particles and evenly distributed in another liquid to form a stable emulsion or mixed liquid.
Equipment features
1. Efficient emulsification: Ultrasonic emulsification mixing equipment can achieve efficient emulsification, mixing and dispersion in a short time, improving production efficiency.
2. Energy saving and environmental protection: The equipment adopts ultrasonic technology, does not need to add chemical reagents, is pollution-free and noise-free, and meets environmental protection requirements.
3. Easy to operate: The equipment is simple to operate and easy to control, and the frequency and power of the ultrasonic wave can be adjusted as needed.
4. Strong adaptability: It is suitable for the emulsification, mixing and dispersion of a variety of liquid materials, such as oil, water, pigments, glue, etc.
Ultrasonic emulsification mixing equipment is widely used in food, chemical, pharmaceutical, cosmetic and other industries. In the food industry, it can be used to make emulsified oil, jam, juice, etc.; in the chemical industry, it can be used to prepare pigments, coatings, glue, etc.; in the pharmaceutical industry, it can be used to prepare drug emulsions, vaccines, etc.; in the cosmetics industry, it can be used to make lotions, creams, etc.
