| Availability: | |
|---|---|
| Quantity: | |
| Place of Origin | China |
|---|---|
| Brand Name | Rps-sonic |
| Certification | CE |
| Model Number | RPS-W20 |
| Minimum Order Quantity | 1pcs |
| Price | negotiable |
| Packaging Details | CARTON |
| Delivery Time | 1DAYS |
| Payment Terms | T/T |
| Supply Ability | 200PCS/MONTH |
15Khz 2600w Ultrasonic mask making machine for mask cutting with customized horn
Parameter
| Item | Parameter |
| Power | 3200W In max |
| Frequency range | ±1khz |
| Operating temperature | ≤65ºC |
| Frequency | 20khz |
| Amplitude adjust | 10%~90% |
| Voltage | 220V |
| Circuit | Digital,separate excitation |
Description
Ultrasonic plastic box welding machine, also known as ultrasonic plastic welding machine, is a professional equipment using ultrasonic welding technology, mainly used for welding plastic boxes. The following is a detailed introduction to the equipment:
Working principle
The working principle of ultrasonic plastic welding machine is based on the principle of high-frequency vibration heat generation. When ultrasonic waves act on the contact surface of thermoplastic plastics, they will generate high-frequency vibrations of tens of thousands of times per second. This high-frequency vibration with a certain amplitude transmits ultrasonic energy to the welding area through the upper weldment. Since the acoustic resistance of the welding area, i.e. the interface between the two welds, is large, local high temperature will be generated. Due to the poor thermal conductivity of plastics, the heat cannot be dissipated in time for a while, and it gathers in the welding area, causing the contact surface of the two plastics to melt rapidly. At this time, a certain pressure is applied to fuse them into one, forming a strong molecular chain, thereby achieving the purpose of welding. The welding strength can be close to the strength of the raw materials.
Structural composition
The ultrasonic plastic welding machine consists of a pneumatic transmission system, a control system, an ultrasonic generator, a transducer, a tool head and a mechanical device. Specific components include a superheater, a pressure reducing valve, an oil mist collector, a commutator, a throttle valve, a cylinder, etc.
Welding method
The ultrasonic plastic welding machine has a variety of welding methods, including fusion, riveting, spot welding, etc., to meet the welding needs of different plastic boxes.
Advantages at a glance
Economical and reliable production
Aesthetic and reliable edge sealing
Cutting and sealing in a single pass
High process repeat accuracy
Various sealing modes and multi-stage processes
Long tool life thanks to Cutting controller
Acoustic expertise even for complex contours
Extensive process control and statistical evaluation
