| Quantity: | |
| Place of Origin | China |
|---|---|
| Brand Name | Rps-sonic |
| Certification | CE |
| Model Number | RPS-C40 |
| Minimum Order Quantity | 1pcs |
| Price | negotiable |
| Packaging Details | CARTON |
| Delivery Time | 1DAYS |
| Payment Terms | T/T |
| Supply Ability | 200PCS/MONTH |
| Frequency | 40Khz | Power | 300w |
|---|---|---|---|
| Blade Material | Titanium | Generator | Digital |
| Voltage | 220/110V | Application | Ultrasonic Fabric Cutter |
| Weight | 8kg | ||
| High Light | Nonwoven Ultrasonic Fabric Cutting Machine,Titanium Blade Ultrasonic Fabric Cutter,300Watt Ultrasonic Fabric Sealing Machine | ||
Product Details
This machine is specially engineered for cutting all types of fabrics. Our cutting machine cut all fabrics with a superb edge seal, which prevents fraying. We integrate advanced technology in this Ultrasonic Fabric Cutter for its fully automated and precise operation.
Through ultrasonic high-frequency vibration, the fabric to be processed is first densely bonded, and the rear blade is followed by the dense pattern to synchronously slit or trim the fabric.
The whole of ultrasonic cutting edge banding machine is composed of ultrasonic generator (drive power) and ultrasonic host (cutting part).
Through ultrasonic high-frequency vibration, the fabric to be processed is densely bonded first, and the rear blade is followed by the dense pattern to synchronize the slitting or trimming of the fabric.
The ultrasonic host is simply installed on the knitting equipment, which can realize the cutting of woven fabrics and ensure that the fabrics are not scattered, hardened, smooth and beautiful; the equipment is safe and reliable in operation.
Mainly used in the processing and weaving industry of chemical fiber textiles, geotextiles, woven fabrics, plastic films and non-woven fabrics; the woven fabrics contain thermoplastic materials such as polypropylene and polyethylene.
Technical advantages
Ultrasonic cutting has the advantages of accurate cutting edge, smooth and reliable cut, no deformation, wire drawing, wrinkle, etc. Edge banding technology
It is the most perfect way of cutting non-woven fabrics at present, with good edge sealing effect and not hard edges.
Two ways of holding or clamping the customer system, convenient for customers to operate and install
The power can be adjusted, and it can be connected to the customer control system
Safely separate and seal the processed objects during work
Beautiful and airtight cutting edges
Special cloth cutting blade, high cutting quality, easy to replace
Completely replace the resistance hot knife cutting process, energy saving and environmental protection
Parameter
| Frequency | 40Khz |
| Frequency adjustment | Auto-tracking type |
| Max. power output | 300W |
| Power output | Infinitive adjustment |
| Power supply | AC200V 50/60Hz |
| Outer dimension (mm) | 120*120*380 |
| Weight | 5kg |
| Horn width | 0.5mm |
Process flexibility
Enhanced precision
Cleaning edages
cost reduce
Energy efficient
worker safety
Enviroment Friendly
No water waste disposal
Ultrasonic cutting sewing equipment is mainly suitable for fabric, suitable materials such as butyrate, cellulose, nylon, polyester, polyethylene, polypropylene, PVC and other materials. It is also suitable for a wide range of tubing in automotive, metal, pharmaceutical, food, cosmetic, medical and scientific applications.
Pictures
| Frequency | 40Khz | Power | 300w |
|---|---|---|---|
| Blade Material | Titanium | Generator | Digital |
| Voltage | 220/110V | Application | Ultrasonic Fabric Cutter |
| Weight | 8kg | ||
| High Light | Nonwoven Ultrasonic Fabric Cutting Machine,Titanium Blade Ultrasonic Fabric Cutter,300Watt Ultrasonic Fabric Sealing Machine | ||
Product Details
This machine is specially engineered for cutting all types of fabrics. Our cutting machine cut all fabrics with a superb edge seal, which prevents fraying. We integrate advanced technology in this Ultrasonic Fabric Cutter for its fully automated and precise operation.
Through ultrasonic high-frequency vibration, the fabric to be processed is first densely bonded, and the rear blade is followed by the dense pattern to synchronously slit or trim the fabric.
The whole of ultrasonic cutting edge banding machine is composed of ultrasonic generator (drive power) and ultrasonic host (cutting part).
Through ultrasonic high-frequency vibration, the fabric to be processed is densely bonded first, and the rear blade is followed by the dense pattern to synchronize the slitting or trimming of the fabric.
The ultrasonic host is simply installed on the knitting equipment, which can realize the cutting of woven fabrics and ensure that the fabrics are not scattered, hardened, smooth and beautiful; the equipment is safe and reliable in operation.
Mainly used in the processing and weaving industry of chemical fiber textiles, geotextiles, woven fabrics, plastic films and non-woven fabrics; the woven fabrics contain thermoplastic materials such as polypropylene and polyethylene.
Technical advantages
Ultrasonic cutting has the advantages of accurate cutting edge, smooth and reliable cut, no deformation, wire drawing, wrinkle, etc. Edge banding technology
It is the most perfect way of cutting non-woven fabrics at present, with good edge sealing effect and not hard edges.
Two ways of holding or clamping the customer system, convenient for customers to operate and install
The power can be adjusted, and it can be connected to the customer control system
Safely separate and seal the processed objects during work
Beautiful and airtight cutting edges
Special cloth cutting blade, high cutting quality, easy to replace
Completely replace the resistance hot knife cutting process, energy saving and environmental protection
Parameter
| Frequency | 40Khz |
| Frequency adjustment | Auto-tracking type |
| Max. power output | 300W |
| Power output | Infinitive adjustment |
| Power supply | AC200V 50/60Hz |
| Outer dimension (mm) | 120*120*380 |
| Weight | 5kg |
| Horn width | 0.5mm |
Process flexibility
Enhanced precision
Cleaning edages
cost reduce
Energy efficient
worker safety
Enviroment Friendly
No water waste disposal
Ultrasonic cutting sewing equipment is mainly suitable for fabric, suitable materials such as butyrate, cellulose, nylon, polyester, polyethylene, polypropylene, PVC and other materials. It is also suitable for a wide range of tubing in automotive, metal, pharmaceutical, food, cosmetic, medical and scientific applications.
Pictures
